Professional mixing console audio mixer sound mixer
Model number: RE8
Technical parameters: Total harmonic distortion :< - 0.005%
Frequency response :20Hz-20 KHZ +1dB /-3dB
Maximum output level :18dBm (1 KHz, THD=0.5%)
Signal to noise ratio :-81 dB
Gain control: mono :-51dB~0dB
Residual output noise :< -83dBu
Crosstalk :< -79dBu
Headphone output power :260mW(1KHz,THD=0.5%, 200Ω)
Equalizer: Low :80Hz±15dB Medium :250Hz to 6KHz±15dB High :12KHz±15dB
Input and output impedance: Microphone input :2.4KΩ mono input :11 KΩ
Output impedance :≤75Ω
Power consumption :35W
Net weight :7kg
Functional features:
(1) 8 Mono input
(2) Built-in professional digital (DSP) effect device with level display light
(3) The neoclassical British 3-band equalizer makes the sound warm and highly musical
(4) Each channel has two auxiliary transmissions
(5) So the sound channel is equipped with peak diode light tube, mute /alt 3-4 function
(6) 2 function stereo auxiliary feedback interface, providing great flexibility
(7) Durable 60mm streamlined push rod and sealed control knob
(8) Flexible use, with no noise, instant response, low power consumption characteristics
(9) With the goods supply rack installation rack, flexibility is extremely strong
(10) High quality components and extremely strong structure, make the product durable
(11) MP3 player with USB input
(12) High-precision three-color level display, which can accurately control the output level
(13) Unique AUX auxiliary input
(14) Each high power noise external power supply
